Product | Orientable and Adjustable
EO 5056-A LED TIGE
Ceiling mounted luminaire for LED SPOT module, maximum 4 685 lumens

Color(s) :

Norms : Class I IP 20 | 650°

Beam(s) :

Driver(s) :

Efficiency Energy Class : D, E
Recessed cut out :
Ø67 mm

Download the technical sheet:

  • MacAdam Ellipse: 3 SDCM
    CRI of 80 or 90
    Available in 2 500 K, 3 000 K, 3 500 K and 4 000 K
    50 000 hours lamp life (L80B10)
    Luminous efficiency of system up to 145,5 lm/W
    Springs in pressure for easier installation
    Ring made of die-cast aluminium
    Static heat sink
    Weight: approx. 1,3 kg
    Driver(s): Fixed, Dimmable driver DALI (CDIMMDALI)
    Option(s): Fast connector (CORD)

Type of lighting Accentuation
Application domain
Color temperature 2500 K, 3000 K, 4000 K
Mounting type
IP 20
