Product | Continuous rows
LC 5141 LED
Suspended continuous row lighting for LINEAR LED module, maximum 25 200 lumens

Color(s) :

Norms : Classe I | IP 20 | 650° | RG0

Driver(s) :

Efficiency Energy Class : C
Recessed cut out :

Download the technical sheet:

CRI of 80
MacAdam Ellipse: 3 SDCM
Available in 3 000 K and 4 000 K
100 000h lamp life L80
50 000h lamp life L90
Luminous efficiency of system up to 183,3 lm/W
Available in single module, in continuous row or discontinuous row lighting
Housing made of prelacquered steel
Cluster optical with lens, made of polycarbonate (PC)
Static heat sink
Optical compartment protected against shocks and dust
Mechanical junction without tools
Trunking length : 1700 mm and 3400 mm
Board length : 1700 mm
If built-in sensor: trunking length 1800 mm et 3500 mm
Board length with sensor : 1800 mm
Driver(s): Fixed, Dimmable driver DALI (CDIMMDALI)
Accessories: line departure kit, suspension bracket, socket supply kit, closing cover
Option(s) : Lighting sensor and-or movement detection (CEL), Independent Unit lighting Security (BAES), Possibility of adding a socket on the shaft or a spotlight
Photobiological risk group 0

Type of lighting Général
Application domain Retail / magasins, GSA, GSS
Color temperature 3000 K, 4000 K
Mounting type
IP 20

Suspension bracket

End cap

Locking cover
