Product | Orientable and Adjustable
EO 2242 LED
Circular recessed orientable spotlight for LED SPOT module, maximum 7 750 lumens
Color(s) :
Adjustable :
Norms : Classe I | IP 20 | 650°
Beam(s) :
Driver(s) :
/Convertisseur_FIXE-GB.jpg){kind=small}
/Convertisseur_DALI.jpg){kind=small}
Efficiency Energy Class : D
Recessed cut out :
Ø195 mm
Ø195 mm
Download the technical sheet:
CRI of 80 or 90
MacAdam Ellipse: 2 SDCM
Available in 3 000 K and 4 000 K
50 000 hours lamp life (L80B10)
Luminous efficiency of system up to 151,2 lm/W
Springs in pressure for easier installation
Ring made of die-cast aluminium
Static heat sink
Weight: Approx. 1,7 kg
Driver(s): Fixed, Dimmable driver DALI (CDIMMDALI)
Option(s): Fast connector (CORD)
| Type of lighting | Accentuation |
| Application domain | Retail / magasins, GSA, GSS, Bureaux, Hôtellerie |
| Color temperature | 3000 K, 4000 K |
| Mounting type | Encastré |
| IP | 20 |
