Product | Track Lighting Luminaires | General Lighting - Led Lighting Fixtures | Éclairage Général – Appareils Led
LS 5017-E LED
Track suspended luminaire for LINEAR LED module(s), maximum 4 579 lumens

Color(s) :

Adjustable :

Norms : Class II IP 20 | 650° | IK 10

Light distribution :

Driver(s) :

Efficiency Energy Class : D

Download the technical sheet:

  • Track suspended luminaire for LINEAR LED module(s), maximum 4 579 lumens
  • CRI of 80
  • MacAdam Ellipse: 3 SDCM
  • Available in 3 000 and 4 000K
  • 50 000 hours lamp life (L80B20)
  • Luminous efficiency of system up to 160 lm/W
  • 3 circuits track adaptor
  • Housing made of prelacquered steel
  • Cluster optical with lens, made of polymethyl methacrylate (PMMA)
  • Static heat sink
  • Optical compartment protected against shocks and dust
  • Weight: approx. 1,4 kg
  • Driver(s): Fixed, Dimmable driver DALI (CDIMMDALI)
  • Option(s) : Double Asymétrique (DASY)

Type of lighting Général
Application domain Retail / magasins, GSA, GSS
Color temperature 3000 K, 4000 K
Mounting type Sur rail 3 allumages
IP 20
