LS 5017-K LED
Track suspended luminaire for LINEAR LED module, maximum 12 750 lumens

Color(s) :

Norms : Class I | IP 20 | 650° | IK 10

Light distribution :

Driver(s) :

Efficiency Energy Class : C
Recessed cut out :

Download the technical sheet:

Track suspended luminaire for LINEAR LED module,
maximum 12 750 lumens
CRI of 80
MacAdam Ellipse : 3 SDCM
Available in 3 000 K and 4 000 K
Middle flux module 100 000 hours lamp life (L80B10),
50 000h (L90B10)
High flux module 100 000 hours lamp life (L90B10)
Luminous efficiency of system up to 186,5 lm/W
3 circuits track adaptor
Housing made of prelacquered steel
Cluster optical composed of lenses, polycarbonate (PC)
Static heat sink
Optical compartment protected against shocks and dust
Driver(s) : Fixed, Dimmable DALI (CDIMMDALI), Casambi, Connect
ENEC-labelled component and driver
Red rendering (R9) : R9>50 ( High flux ), R9>0 ( Middle flux )

Type of lighting Général
Application domain Retail / magasins, GSA, GSS
Color temperature 3000 K, 4000 K
Mounting type Sur rail 3 allumages
IP 20
